Overview

The Bently Nevada 330130-060-10-00 Extension Cable is designed for use with the 3300 XL 8 mm Proximitor Sensor and probes. It features robust engineering to ensure accurate performance and durability, making it an essential component for monitoring applications. Enhanced with patented CableLoc and TipLoc technologies, this extension cable offers high reliability and fluid resistance, ideal for demanding industrial environments.

Key Features and Specifications

• Brand: Bently Nevada
• Model: 330130-060-10-00
• Suffix Meaning:
  • 060: Cable length of 6.0 meters (19.7 feet).
  • 10: FluidLoc cable option for preventing oil and liquid leaks.
  • 00: No special approvals required.

Cable Options and Weight

• Standard Extension Cable:
  • Weight: 34 g/m (0.4 oz/ft)
  • Total weight: 0.204 kg

Electrical Characteristics

• Capacitance: 69.9 pF/m (21.3 pF/ft)
• Nominal DC Resistance:
  • Center Conductor (RCORE): 1.32 ± 0.21 Ω for 6.0 meters.
  • Outer Conductor (RJACKET): 0.39 ± 0.08 Ω for 6.0 meters.

Environmental and Operating Conditions

• Operating Temperature: +18˚C to +27˚C (+64˚F to +80˚F).
• Recommended Target Material: AISI 4140 steel for optimal performance.
• Power Supply Requirements: -17.5 Vdc to -26 Vdc, with a maximum consumption of 12 mA.

Linear Range

• Effective range: 2 mm (80 mils) starting from 0.25 mm (10 mils) up to 2.3 mm (90 mils).

Application Insights

This extension cable is specifically engineered for monitoring in turbine oil applications, industrial machinery, and high-vibration environments. The FluidLoc option ensures no fluid seepage through the cable, improving reliability. Additionally, the provided silicone tape offers an alternative to connector protectors for most setups.
