Bently Nevada 3300 XL 8mm Proximity Probe (330101-00-12-10-12-00)

Description

The Bently Nevada 3300 XL 8mm Probe is a rugged industrial sensor designed for precise vibration and position monitoring. Featuring a 3/8-24 UNF thread and PPS plastic tip, it offers superior durability with patented TipLoc and CableLoc technology for enhanced pull strength (330N/75 lbf). Ideal for harsh environments, it includes FluidLoc cable option to prevent oil leakage. Made in USA.

Technical Data

• Brand: Bently Nevada (GE Subsidiary)
• Model: 3300 XL 8mm Probe [Full Suffix: 330101-00-12-10-12-00]
• Thread: 3/8-24 UNF, unarmored
• Unthreaded Length: 0.0 in (00)
• Case Length: 1.2 in (12)
• Cable: 1.0m FluidLoc with Miniature Coaxial ClickLoc (12)
• Linear Range: 0.25–2.3mm (10–90 mils)
• Output: -9Vdc @1.27mm gap (200mV/mil ±5%)
• Temperature: -52°C to +177°C (Standard)
• Pressure Seal: Viton® O-ring (untested)

Key Features

• 8mm Diameter – Thicker PPS encapsulation for extreme durability
• Patented CableLoc – 75 lbf pull resistance
• Stainless steel case (AISI 303/304)
• Compatible with 3300 XL monitors (≤305m field wiring)

Industrial Solutions

Solve common pain points:

• Oil Leakage: FluidLoc cable blocks liquid ingress
• Cable Damage: Reinforced strain relief
• High Temp: ETR version available (+260°C)

Compare Models

FAQ

• Q: Warranty?
  A: 12 months, excludes COO.
• Q: Shipping?
  A: FedEx/UPS/DHL worldwide.
• Q: Installation gap?
  A: Set to -9Vdc (~1.27mm).

Package Includes

• 3300 XL 8mm Probe (330101-00-12-10-12-00)
• 1.0m FluidLoc cable with ClickLoc connector
• Installation guide (no certificate included)
