330101-00-24-10-02-00 Bently Nevada Proximity Probe
Manufacturer:
Bently Nevada
Product No.:
330101-00-24-10-02-00
Condition:
In Stock
Product Type:
Proximity Probe
Product Origin:
USA
Weight:
323g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Technical Specifications
Part Information
| Parameter | Value |
|---|---|
| Part Number | 330101-00-24-10-02-00 |
| Model | 3300 XL 8 mm Probe |
| Thread Size | 3/8-24 UNF thread |
| Unthreaded Length | 0.0 inches (00 option) |
| Overall Case Length | 2.4 inches (24 option) |
| Total Length | 1.0 meter (3.3 feet) (10 option) |
| Connector Type | Miniature coaxial ClickLoc connector (02 option) |
| Cable Type | Standard cable (02 option) |
| Agency Approval | Not required (00 option) |
Measurement Performance
| Parameter | Value |
|---|---|
| Linear Range | 80 mils (2.0 mm) |
| Sensitivity | 7.87 V/mm (200 mV/mil) |
| System Accuracy | ±0.5% of full-scale output when used with Bently Nevada 3300 monitoring systems. |
| Temperature Range | Operating: -35°C to +177°C (-31°F to +351°F) Storage: -51°C to +177°C (-60°F to +351°F) |
| Relative Humidity | 100% condensing, fully sealed construction. |
Mechanical Specifications
| Parameter | Value |
|---|---|
| Probe Tip Diameter | 8 mm (0.315 inches) |
| Probe Body Material | 300 series stainless steel |
| Probe Tip Material | PEEK (Polyether Ether Ketone) |
| Cable Material | Fluorocarbon (FEP) insulation |
| Minimum Bend Radius | 1.5 inches (38 mm) |
