Bently Nevada 3300 XL 8mm Long-Reach Vibration Probe

The Bently Nevada3300 XL 8mm probe delivers exceptional vibration monitoring with extended 9-meter cable. This industrial sensor features advanced engineering for challenging applications requiring long-distance signal transmission. The extended reach model maintains precise measurements across complex machinery layouts.

Extended Configuration Profile

• Core Model: 3300 XL 8mm Vibration Monitoring Probe
• Complete Part Identification: 330101-00-28-90-02-00
• Mechanical Connection: 3/8-24 UNF threaded interface
• Unthreaded Segment: 0.0 inches (00 designation)
• Extended Housing: 2.8 inches case length (28 option)
• Maximum Cable Reach: 9.0 meters (29.5 feet total length)
• Connection System: Miniature coaxial ClickLoc connector
• Certification Status: No special approvals required (00)

Advanced Technical Capabilities

• Extended 9-meter cable enables flexible installation layouts
• 2.8-inch case length provides deeper mounting capability
• TipLock patented molding ensures permanent tip integrity
• CableLock technology withstands 330 Newton pulling forces
• 8mm robust construction resists physical impact damage
• PPS thermoplastic maintains stability at high temperatures
• Stainless steel housing provides corrosion resistance
• Miniature ClickLoc connector ensures reliable connections
• Extended temperature range from -52°C to +177°C

Extended Range Performance Data

• Measurement Range: 2.0mm linear operational span
• Frequency Response: 0 to 10kHz with 9-meter cable
• Output Sensitivity: 7.87 V/mm ±6.5% for long systems
• Linearity Accuracy: ±0.038mm maximum deviation
• Electrical Resistance: 9.87Ω ±0.50 for 9-meter length
• Cable Characteristics: 69.9 pF/m typical capacitance
• Signal Output: -1 to -17 Vdc corresponding to gap
• Optimal Gap Setting: 1.27mm for vibration monitoring
• Maximum System Length: 305 meters total field wiring
• Temperature Operating Range: -52°C to +177°C standard
• Extended Thermal Capability: -52°C to +218°C probe tip
• Humidity Performance: 93% RH with minimal ASF change

Installation & Setup Guidelines

• Utilize 3/8-24 UNF threading for secure probe mounting
• Set operational gap to achieve -9 Vdc output voltage
• Employ 0.2-1.5mm² shielded triad cable for field wiring
• Maintain minimum bend radius of 25mm for cable protection
• Ensure target surface exceeds probe diameter by 1.5 times
• Verify proper ClickLoc connector engagement during setup
• Check system frequency response for extended cable runs
