330101-32-53-10-02-00 Bently Nevada 3300 XL 8 mm Probe

In stock
Manufacturer:
Bently Nevada
Product No.:
330101-32-53-10-02-00
Condition:
In Stock
Product Type:
3300 XL 8 mm Proximity Probe
Product Origin:
USA
Weight:
323g
Shipping port:
Xiamen
Warranty:
12 months

UBEST – Trusted Global Automation Parts Supplier

We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.

About Us | Contact

Bently Nevada 3300 XL 8mm Proximity Probe (330101-32-53-10-02-00)

Industrial-grade shaft monitoring with enhanced durability for critical machinery. Made in USA with optional COO certificate.

FULL MODEL SUFFIX

Code Option Specification
-32 Unthreaded Length 3.2 in
-53 Case Length 5.3 in
-10 Total Length 1.0m (3.3 ft)
-02 Connector Mini coaxial ClickLoc
-00 Approvals Not required

TECHNICAL SPECIFICATIONS

  • Thread: 3/8-24 UNF
  • Resistance: 7.59Ω ±0.50 (1m)
  • Cable Capacitance: 69.9 pF/m
  • Linear Range: 2mm (80 mils)
  • Scale Factor: 7.87 V/mm ±5%
  • Accuracy: ±0.025mm (±1 mil)
  • Tip Material: PPS plastic
  • Case Material: 304/316 SST

ENVIRONMENTAL RATINGS

  • Temp Range: -52°C to +177°C
  • Humidity: <3% ASF change @93% RH
  • Pressure Seal: Viton® O-ring
  • Weight: 323 g/m (11.4 oz)
  • Min Temp Warning: Avoid below -34°C

INSTALLATION GUIDE

  • Optimal Gap: 1.27mm (50 mils)
  • Wiring: 0.2-1.5mm² shielded triad
  • Max Cable: 305m (1,000 ft)
  • Field Wiring: Tinned copper recommended

COMPATIBILITY

  • Works with all 3300 XL monitoring systems
  • Standard ClickLoc connector interface
  • Certified for use with 0217-xxxx cables

PACKAGE CONTENTS

  • 1x 8mm Proximity Probe
  • Note: COO certificate available separately

SHIPPING & WARRANTY

  • Global carriers: FedEx, UPS, DHL
  • 12-month manufacturer warranty

FAQ

Q: What's the minimum installation temperature?
A: Do not install below -34°C to preserve pressure seal

Q: Can this probe handle oil immersion?
A: Viton sealed but requires FluidLoc option for fluid blocking

Q: What's the maximum measurable gap?
A: 2.3mm (90 mils) linear measurement range

Q: Is calibration certification included?
A> Calibration not provided; COO available separately

ALTERNATIVE MODELS

Model Length Connector Compare
330101-32-53-10-02-00 1.0m ClickLoc Current Item
330101-00-22-05-02-CN 0.5m ClickLoc View
330101-00-20-50-02-CN 5.0m ClickLoc View
330101-00-12-10-01-CN 1.0m BNC View
