🌟 Overview

The Bently Nevada 330105-02-12-15-02-05 is a high-precision reverse mount proximity probe designed for industrial vibration monitoring applications. With its 3/8-24 UNF thread, 1.5-meter cable, and Miniature ClickLoc coaxial connector, it ensures reliable operation in extreme conditions. This probe is CSA, ATEX, and IECEx approved, making it suitable for hazardous environments.

🔧 Technical Specifications

📌 General Information

• Brand: Bently Nevada

• Model: 330105-02-12-15-02-05

• Product Type: Reverse Mount Probe

• Country of Origin: U.S.A

📌 Ordering Information

• Model: 330105-02-12 (3/8-24 UNF thread)

• Total Length Option: 15 (1.5 meters / 4.9 feet)

• Connector Type: 02 (Miniature ClickLoc coaxial connector)

• Agency Approval: 05 (CSA, ATEX, IECEx Approvals)

📌 Physical Characteristics

• Dimensions: 20.4 cm x 22.2 cm x 3.7 cm

• Weight: 0.323 kg

• Probe Tip Material: Polyphenylene sulfide (PPS)

• Probe Case Material: AISI 303 or 304 stainless steel

📌 Mechanical Properties

• Torque Rating:

  • Maximum Rated: 22.6 N•m (200 in•lbf)

  • Recommended: 7.5 N•m (66 in•lbf)

• Thread Type: 3/8-24 UNF

• Maximum Thread Engagement Length: 0.563 inches

📌 Electrical Characteristics

• Nominal Probe DC Resistance: 7.73 ± 0.50 Ω (for 1.5-meter length)
