330106-05-30-10-12-05 Bently Nevada 3300 XL 8mm Proximity Probe
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Bently Nevada 330106-05-30-10-12-05 Reverse Mount Probe - Hazardous Area Certified
High-temperature reverse-mount proximity probe with FluidLoc cable and triple agency approvals. Features M10x1 threading and PPS tip for reliable machinery monitoring in extreme conditions.
SUFFIX CONFIGURATION DECODED
Thread Type
M10x1
Probe Type
8mm Reverse Mount
Cable Length
1.0m (3.3ft)
Connector
ClickLoc + FluidLoc
Approvals
CSA/ATEX/IECEx
TECHNICAL SPECIFICATIONS
| Parameter | Specification |
|---|---|
| DC Resistance | 7.59Ω ±0.50Ω (1m cable) |
| Thread Engagement | 15mm max |
| Temperature Range | -52°C to +218°C (tip) -51°C to +260°C (cable) |
| Pressure Seal | Viton O-ring (custom test available) |
| Humidity Tolerance | <3% ASF change at 93% RH (56 days) |
| Cable Construction | 75Ω triaxial with FEP/PFA insulation |
| Tensile Strength | 330N (probe to lead) 270N (lead to connector) |
| Weight | 323 g/m (11.4 oz/ft) |
PACKAGE CONTENTS
- 3300 XL reverse mount probe
- Miniature ClickLoc connector
- Installation documentation
- Factory-sealed packaging
SHIPPING & WARRANTY
Global delivery via FedEx, UPS, DHL. 12-month manufacturer warranty. Made in USA.
COMPARISON WITH SIMILAR PROBES
| Model | Cable Length | Connector | Approvals | Link |
|---|---|---|---|---|
| 330106-05-30-10-12-05 | 1.0m | FluidLoc | CSA/ATEX/IECEx | Current |
| 330106-05-30-05-02-05 | 0.5m | Standard | CSA/ATEX/IECEx | Compare |
| 330106-05-30-20-02-00 | 2.0m | Standard | None | Compare |
FREQUENTLY ASKED QUESTIONS
Q: When is FluidLoc cable necessary?
A: Recommended for direct fluid exposure applications without protective sleeves.
Q: Minimum installation temperature?
A: Avoid below -34°C (-30°F) to prevent seal damage.
Q: What's the probe tip material?
A: Chemical-resistant Polyphenylene Sulfide (PPS).
Q: Can I get pressure testing certification?
A: Custom testing available through Bently Nevada design department.
