Bently Nevada 3300 XL 8mm Reverse Mount Proximity Probe

Precision Machinery Monitoring

New Made in USA reverse-mount probe designed for challenging installations. Features Viton® pressure sealing and PPS tip for chemical resistance. Ideal for confined spaces requiring rear-access mounting.

Technical Specifications

• Brand: Bently Nevada
• Full Model: 330106-05-30-20-12-00
• Configuration:
  • 330106: 8mm reverse mount base
  • -05-: M10x1 thread
  • -30-: Standard case configuration
  • -20-: 2.0m cable (6.6 ft)
  • -12-: Mini ClickLoc + FluidLoc
  • -00: No agency approval
• DC Resistance: 7.88Ω ±0.50
• Temp Range: -52°C to +177°C
• Cable Tensile Strength: 330N (75 lbf)
• Humidity Stability: <3% ASF change @93% RH
• Weight: 323 g/m (11.4 oz)

Installation Notes

• Thread Engagement: Max 15mm
• Pressure Seal: Viton® O-ring (not pre-tested)
• FluidLoc Warning: Usually unnecessary with probe sleeve
• Cold Temp Limit: Avoid below -34°C to prevent seal failure

Materials & Construction

• Tip: PPS polymer
• Case: AISI 303/304 SST
• Connector: Gold-plated brass/beryllium copper
• Cable Options: Standard FEP or extended-range PFA

Packaging & Warranty

• Factory-sealed original packaging
• 12-month manufacturer warranty

Global Shipping

FedEx/UPS/DHL | 3-7 business days worldwide

FAQ

Q: When is FluidLoc cable unnecessary?
A: In most installations due to existing probe sleeve protection

Q: Minimum operating temperature?
A: -52°C but avoid sustained use below -34°C to preserve seal
