Overview

The Bently Nevada 330130-030-02-00 3300 XL Extension Cable is a high-performance accessory specifically engineered to enhance the reliability of vibration monitoring systems. Known for its durability, this cable is designed to operate in extreme temperatures, making it ideal for demanding industrial environments. Featuring advanced technologies like TipLoc molding and CableLoc design, the product ensures secure connectivity and exceptional performance over extended operational periods.

Technical Specifications

• Manufacturer: Bently Nevada
• Model: 330130-030-02-00
• Cable Length: 3.0 meters (9.8 feet)
• Connector & Cable: Standard cable with connector protector (Option 02)
• Agency Approval: Not required (Option 00)
• Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft) typical
• Operating Temperature Range: -51 °C to +177 °C (-60 °F to +351 °F)
• Weight: 0.102 kg
• Linear Range: 2 mm (80 mils), from 0.25 to 2.3 mm (10 to 90 mils)
• Field Wiring: Supports 16 to 24 AWG, with a maximum length of 305 meters (1,000 feet) between the Proximitor Sensor and monitor.
• Power Supply Requirements: -17.5 Vdc to -26 Vdc (12 mA max); operation at -23.5 Vdc or higher may reduce linear range.
• Output Resistance: 50 Ω

Understanding the Model Number

• 330130: Identifies the product series as the 3300 XL Extension Cable.
• 030: Denotes the cable length of 3.0 meters (9.8 feet).
• 02: Indicates the standard cable with a connector protector.
• 00: Specifies that no agency approval is required.

Frequently Asked Questions (FAQ)

• 1. Can the 3300 XL extension cable be used in extreme environments?
  Yes, the cable operates effectively between -51 °C and +177 °C, making it suitable for a wide range of applications.
• 2. What is the advantage of the CableLoc design?
  The CableLoc design provides a pull strength of 330 N (75 lbf), ensuring a secure attachment and minimizing detachment risks.
• 3. What are the compatibility requirements?
  This cable is designed to work exclusively with Bently Nevada 3300 XL 8 mm probes and Proximitor Sensors.
• 4. Is the FluidLoc technology available for this model?
  Yes, the FluidLoc option can be added to prevent liquid leaks through the cable.
• 5. What field wiring recommendations apply?
  It is recommended to use shielded triad cables with tinned field wiring for optimal performance.
