Overview

The Bently Nevada 330130-040-10-00 extension cable is a high-performance accessory designed for industrial vibration monitoring systems. With its FluidLoc cable option, it effectively prevents the leakage of oil or other liquids. This cable is engineered to meet rigorous requirements for reliability and durability, ensuring optimal performance in demanding environments. Additionally, a patented CableLoc design enhances pull strength, while included silicone tape provides additional protection against harsh conditions.

Technical Specifications

• Brand: Bently Nevada
• Model: 330130-040-10-00
• Cable Length: 4.0 meters (11.5 feet)
• Connector Protector Option: FluidLoc cable for enhanced sealing
• Approvals: Not required (00 suffix)
• DC Resistance:
  • Center Conductor: 0.88 ± 0.13 Ω (for 4.0 m length)
  • Outer Conductor: 0.26 ± 0.05 Ω (for 4.0 m length)
• Capacitance: 69.9 pF/m (21.3 pF/ft)
• Field Wiring Compatibility: 16 to 24 AWG shielded triad cable, maximum length of 305 m (1,000 ft)
• Linear Range: 0.25 mm to 2.3 mm (10 mils to 90 mils)
• Power Supply Requirements: -17.5 Vdc to -26 Vdc with 12 mA maximum consumption
• Output Resistance: 50 Ω

Frequently Asked Questions (FAQ)

• 1. What is the FluidLoc cable option?
  The FluidLoc cable option prevents fluids from seeping through the interior of the cable, ensuring contamination-free operation.
• 2. Can this cable be used with other Bently Nevada systems?
  Yes, the 330130-040-10-00 cable is designed for compatibility with the 3300 XL 8 mm Proximitor Sensor and related systems.
• 3. What is the purpose of silicone tape?
  Silicone tape is provided as an alternative to connector protectors, offering added sealing protection in appropriate environments.
• 4. What does the model suffix represent?
  The suffix indicates specific characteristics: cable length (040 for 4.0 m), FluidLoc option (10), and approval type (00).
• 5. Is the cable resistant to turbine oil?
  The FluidLoc option provides superior sealing against liquids, but silicone tape is not recommended for turbine oil exposure.
