Bently Nevada Armored Extension Cable: Heavy-Duty Protection

This Bently Nevada 330130-070-01-05 armored extension cable offers superior protection. It connects vibration probes to monitoring systems securely. The armored design resists physical damage and harsh conditions. It ensures reliable signal transmission in demanding industrial applications.

Product Configuration Details

• 330130 - 3300 XL Extension Cable Base
• 070 - Cable Length: 7.0 meters
• 01 - Armored Cable Construction
• 05 - CSA, ATEX, IECEx Certifications

Complete Technical Specifications

• Cable Length: 7.0 meters (22.9 feet)
• DC Resistance (Center): 1.54 ± 0.23 ohms
• DC Resistance (Outer): 0.46 ± 0.09 ohms
• Cable Capacitance: 69.9 pF per meter
• Operating Voltage: -17.5 Vdc to -26 Vdc
• Current Consumption: 12 mA maximum
• Output Resistance: 50 ohms typical
• Armored Weight: 103 g/m (0.618 kg total)
• Standard Weight: 34 g/m (0.204 kg total)
• Field Wiring: 0.2 to 1.5 mm² (16-24 AWG)
• Maximum Field Length: 305 meters
• Linear Range: 0.25 to 2.3 mm (10-90 mils)
• Humidity Resistance: 93% for 56 days
• Included: Silicone tape for connections

Key Product Advantages

• Armored protection against physical damage
• Multiple international safety certifications
• Long 7-meter length for flexible installation
• Low resistance for minimal signal loss
• Works with all 3300 XL system components
• Resists oil and fluid penetration
• Stable performance in humid conditions
• Includes protective silicone tape
• Reliable connection in vibration environments

Installation Instructions

• Use provided silicone tape for connections
• Maintain voltage between -17.5V and -26V
• Keep field wiring under 305 meters maximum
• Use shielded triad cable for best results
• Set probe gap at 1.27 mm for optimal performance
• Avoid exposure to turbine oil at connections

Package Contents

• One 7.0 meter armored extension cable
• Protective silicone tape included
• Quality assurance documentation
• Certification papers for approvals
• Fast shipping via FedEx, UPS, or DHL
• 12 month manufacturer warranty

Technical Questions Answered

• What certifications does this cable have?
  It carries CSA, ATEX, and IECEx international approvals.
• How much does the armored cable weigh?
  Total weight is 0.618 kg for the 7-meter length.
• What is the maximum field wiring distance?
  You can run up to 305 meters from sensor to monitor.
• Does it include connection protection?
  Yes, silicone tape is included for connection sealing.
• What voltage range does it require?
  It operates on -17.5 Vdc to -26 Vdc power supply.
