330171-00-40-10-02-00 Bently Nevada Proximity Probe
Manufacturer:
Bently Nevada
Product No.:
330171-00-40-10-02-00
Condition:
In Stock
Product Type:
Proximity Probe
Product Origin:
USA
Weight:
200g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Technical Data
- Manufacturer: Bently Nevada
- Part Number:330171-00-40-10-02-00
- Product Type: 3300 XL 11 mm Proximity Probe
- Product Description: 3300 XL 11 mm Probe, 1/2-20 UNF Thread, Unarmored
| Parameter | Value |
|---|---|
| Unthreaded Length Option | 00 = 0.0 in. |
| Overall Housing Length Option | 40 = 4.0 in. |
| Overall Length Option | 10 = 1.0 m (3.3 ft.) |
| Connector and Cable Type Option | 11 = Micro Coaxial ClickLoc Connector, Standard Cable |
| Agency Approvals Option | 05 = No certification required |
| Probe Tip Material | Polyphenylene sulfide (PPS) |
| Probe Housing Material | AISI 304 stainless steel (SST) |
| Probe Cable Specifications | 75 Ω triaxial, fluorinated ethylene propylene (FEP) insulated probe cable, total probe length: 1, 5, or 9 meters |
| Operating and Storage Temperature | -51°C to +177°C (-60°F to +351°F) |
| Probe Diameter | 11 mm |
| Probe Tip Length | 1.5 mm |
| Probe Tip Material Hardness | 70-80 Shore D |
| Probe Cable Outer Diameter | 6.35 mm |
| Probe Cable Length | 1.0 meter |
| Probe Cable Tensile Strength | 22.24 N |
| Probe Cable Insulation Resistance | 100 MΩ |
| Probe Cable Capacitance | 150 pF/meter |
| Probe Cable Operating Frequency | 0-100 kHz |
| Probe Cable Impedance | 75 Ω |
| Probe Frequency Response | 0-100 kHz |
| Probe Sensitivity | 10 mV/mm |
| Probe Linearity | ±0.5% |
| Probe Repeatability | ±0.1% |
| Probe Stability | ±0.2% |
| Probe Temperature Drift | ±0.01%/°C |
