Bently Nevada 330904-00-15-50-12-05 NSv Proximity Probe

Discover the exceptional Bently Nevada 3300 NSv proximity probe. This 330904-00-15-50-12-05 model is factory new and authentic. It arrives in original sealed packaging. Includes a full 12-month warranty. Fast global shipping via FedEx, UPS, and DHL.

Complete Model Number Explanation

• 330904: Base model with M8x1 thread and protective armor
• -00-: Zero mm unthreaded section length
• -15-: 150 mm total case length
• 50: 5.0 meter extended cable length
• 12: Miniature ClickLoc connector with FluidLoc cable
• 05: Multiple international agency certifications included

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 NSv Proximity Probe
• Complete Part Number: 330904-00-15-50-12-05
• DC Resistance: 5.3 ± 0.7 ohms
• Cable Length: 5.0 meters (16.4 feet)
• Measurement Range: 1.5 mm (60 mils)
• Output Signal: -1 to -13 Vdc
• Sensitivity: 7.87 V/mm (200 mV/mil)
• Frequency Response: 0 to 10 kHz
• Temperature Range: -52°C to +177°C (-62°F to +351°F)
• Case Material: AISI 304 Stainless Steel
• Probe Tip: Polyphenylene Sulfide (PPS)
• Cable Type: FluidLoc chemical-resistant cable
• Minimum Target Size: 8.9 mm diameter
• Maximum Torque: 0.56 N•m (5 in•lb)
• Bend Radius: 25.4 mm minimum

Package Contents

• One genuine Bently Nevada 330904-00-15-50-12-05 probe
• Original factory packaging with certification documents
• 12-month comprehensive warranty coverage
• International express shipping options

Compare With Other Models

This model features extended 150mm case length and international certifications. For different requirements, consider these alternatives:

330904-08-15-10-01-00 - Features 80mm unthreaded section and shorter 1.0m cable

330904-00-10-05-12-00 - Compact 100mm case with shorter 0.5m FluidLoc cable
