330908-22-31-10-01-05 Bently Nevada Proximity Transducer
Manufacturer:
Bently Nevada
Product No.:
330908-22-31-10-01-05
Condition:
In Stock
Product Type:
Proximity Transducer
Product Origin:
USA
Weight:
100g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Technical Specifications
| Parameter | Value |
|---|---|
| Thread Size | 3/8-24 UNF |
| Unthreaded Length | 2.2 inches (5.6 cm) |
| Overall Case Length | 3.1 inches (7.9 cm) |
| Probe Tip Diameter | 5 mm, designed for precise measurements in tight spaces |
| Cable Length | 1.0 meter (39 inches) |
| Probe Housing Material | Stainless steel, providing robust protection in harsh environments |
| Connector Type | Miniature coaxial ClickLoc connector with connector protector |
| Operating Temperature | -35°C to +177°C (-31°F to +350°F) |
| Vibration Range | 0 to 50 g peak |
| Linear Range | 0.25 mm to 2.0 mm (10 mils to 80 mils) |
| Sensitivity | 7.87 mV/μm (200 mV/mil), providing accurate measurement of vibration and displacement |
| Frequency Response | 0 Hz to 10 kHz |
| Power Supply | -24V DC |
| Enclosure Rating | IP68 |
Dimensions
| Parameter | Value |
|---|---|
| Length | 12.4 cm (including connector and cable) |
| Diameter | 2.2 cm (probe tip diameter) |
| Weight | 0.1 kg (including cable and connector) |
