Product Information: Bently Nevada 125840-01 High Voltage AC Power Input Module

Manufacturer: Bently Nevada

Model Number: 125840-01

Product Type: High Voltage AC Power Input Module

Series: 3500

Description:

The Bently Nevada 125840-01 High Voltage AC Power Input Module is a crucial component of the 3500 series monitoring system, designed to provide reliable power to the 3500 series monitors and sensors. This module is responsible for converting high voltage AC power, up to 600VAC, into the low voltage DC power required by the 3500 system. It ensures efficient and consistent power delivery, supporting the optimal operation of the monitoring system.

Features:

• Converts high voltage AC power to low voltage DC power for 3500 series components
• High efficiency, up to 90%
• Robust operating temperature range, suitable for various environments
• Designed for mounting on the 3500 system backplane
• Compact and lightweight design

Specifications:

• Input Voltage:
  • Nominal: 220 Vac
  • Range: 175 to 264 Vac rms, 247 to 373 Vac peak
• Output Current:
  • 2.3 A rms (maximum)
• Efficiency:
  • Up to 90%
• Operating Temperature:
  • -30°C to +65°C (-22°F to +150°F)
• Storage Temperature:
  • -40°C to +85°C (-40°F to +185°F)
• Humidity:
  • 0 to 95% non-condensing
• Mounting:
  • Mounts on Bently Nevada 3500 system backplane
• Dimensions (Height x Width x Depth):
  • 120.7 mm x 25.4 mm x 114.3 mm (4.75 in x 1.0 in x 4.5 in)
• Weight:
  • 0.34 kg (0.75 lb.)

The Bently Nevada 125840-01 High Voltage AC Power Input Module is essential for ensuring the 3500 series monitoring system operates reliably and efficiently, converting high voltage AC to the necessary low voltage DC power required by the system's monitors and sensors. Its compact design and robust specifications make it an ideal choice for a wide range of industrial applications.
