Discover the Triconex 3505E Digital Input Module

Key Technical Specifications

• The Triconex 3505E supports an operating voltage of 24V AC or DC, with a broad input range from 20V to 28V AC/DC.
• This 32-channel module features a low typical input current of 6 mA and an input impedance of 4 kΩ.
• It provides excellent signal isolation, rated at 1500V AC between channels and logic circuits.
• The module boasts a strong common mode rejection ratio of 60 dB at 50/60 Hz for superior noise immunity.
• A consistent input signal delay of just 4 ms ensures rapid and reliable data processing.

Environmental Durability & Compliance

• The operating temperature range spans from 0°C to 60°C, suitable for many industrial settings.
• You can store the module in harsh conditions, with a storage temperature range from -40°C to 85°C.
• It handles high humidity levels between 5% and 95% without any condensation forming.
• The design withstands vibrations up to 1.5 mm amplitude within a 10-55 Hz frequency range.

Packaging & Delivery

• Each unit weighs approximately 5 kilograms and comes securely packaged.
• We ship all orders promptly using reliable carriers like FedEx, UPS, and DHL.
• The package includes the Triconex 3505E Digital Input Module and all necessary mounting hardware.

Frequently Asked Questions

• How many input channels does this module have? The module provides 32 digital input channels.
• What is the operating voltage? It operates on 24V AC/DC, accepting voltages from 20V to 28V.
• Is this module resistant to electrical noise? Yes, its 60 dB common mode rejection effectively minimizes interference.
• How do I install the module? Please refer to the official installation guide for detailed instructions.
