Triconex 3807 Analog Output Module: Reliable 4-Point TMR Analog Interface

The Triconex 3807 Analog Output Module delivers high-performance current output for industrial automation. This robust module provides four isolated bipolar outputs with exceptional accuracy. Engineers trust the 3807 for critical applications requiring reliable analog signal control.

Technical Specifications

• Brand: Triconex
• Model: 3807 | Analog Output Module
• Type: TMR, Analog Output (AO)
• Output Current Range: -60 mA to 60 mA
• Number of Points: 4 bipolar outputs
• Isolation: No, commoned return, DC coupled
• Resolution: 13 bits
• Output Accuracy: < 0.25% of Full Scale Range (FSR)
• Full Scale Range (FSR): 120 mA
• External Loop Power: 24 VDC –15% / +20%
• Maximum Load: 150 ohms at ±60 mA
• Over-range Protection: +36 VDC, continuous
• Switch Time on Leg Failure: < 10 ms (typical)

Diagnostics & Indicators

• The module includes clear diagnostic indicators for easy monitoring.
• These status lights show PASS, FAULT, ACTIVE, and LOAD conditions.
• It also provides separate indicators for power supplies PWR1 and PWR2.
• A light green color code helps with quick visual identification.

Installation & Compatibility

• Install the module in a suitable Triconex chassis or rack.
• Ensure the external loop power supply meets the 24 VDC requirement.
• Verify the load impedance does not exceed the 150-ohm maximum specification.
• The module provides excellent noise immunity in harsh industrial environments.

Packaging & Shipping

• Each order includes one Triconex 3807 Analog Output Module.
• We ship all orders promptly using reliable carriers like FedEx, UPS, or DHL.
• The product arrives securely packaged to prevent any damage during transit.

Frequently Asked Questions (FAQ)

• What is the output type of the 3807 module?
  It is a 4-point, bipolar analog current output module.
• What is the maximum load it can drive?
  It can drive a maximum load of 150 ohms.
• What power supply does it require?
  It requires an external 24 VDC loop power supply.
• How do I know if the module is working correctly?
  Use the built-in status indicators for PASS, FAULT, and other states.
