Brand Information

Brand: GE Fanuc

Series: Series 90-30

Manufacturer: GE Fanuc (Former); Emerson Automation (Current)

Part Details

Part Number:IC693ALG220

Module Type: Input Module

Product Description: Analog input module

Specifications

• Input Signals: +/-10 VDC
• Number of Inputs: 4
• Number of Channels: Four (4)
• Converter Resolution: 12-bit
• Product Type: Channel analog voltage module

Performance

• Input Signals Range: -10 to +10 VDC
• Absolute Accuracy:
  • ±10 mV/40 µA (typical) over operating temperature
  • ±30 mV/160 µA (maximum) over operating temperature
• Linearity: <1 Least Significant Bit
• Isolation: 1,500V between field side and logic side
• Cross-Channel Rejection: >80db

Digital Resolution

Resolution: 5 mV/20 µA, (1 LSB = 5 mV)

Digital Resolution: 12 bits, typical

Cross-Channel Rejection: > 80 db

Operational Characteristics

Update Rate: 4 ms

Input Filter Response: 17 Hz

Weight

Weight: 0.45 kg
