485-00230 TR-Electronic SSI Display Relay Output

In stock
Manufacturer:
TR Electronic
Product No.:
485-00230
Condition:
In Stock
Product Type:
SSI Display
Product Origin:
DE
Weight:
400g
Shipping port:
Xiamen
Warranty:
12 months

UBEST – Trusted Global Automation Parts Supplier

We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.

About Us | Contact

TR-Electronic 485-00230 – 6-Decade SSI Display with Relay Outputs

  • Brand: TR-Electronic
  • Model: 485-00230
  • Author: Ubest Automation
  • Display digits: 6 decades, 14 mm red LED
  • SSI signal input: Single-turn or multi-turn
  • Resolution range: 10 to 25 bit
  • Code formats: Binary or Gray
  • Clock output driver: RS422/RS485
  • Master mode clock: Internal 100 kHz or 200 kHz
  • Slave mode clock: External up to 125 kHz
  • Conversion rate: Approx. 28 values/second
  • Digital user inputs: 2 inputs (programmable function, 10kΩ to +5V)
  • Input logic: NPN, max 30V (L<0.4V / H>3.5V)
  • Alarm outputs: 2 relays (programmable as NO or NC)
  • Front LEDs: 2 for status signaling
  • Relay switch voltage: 250V AC / 250V DC
  • Relay switch current: 5A AC / 5A DC
  • Relay switch power: 750 VA / 100 W
  • Analog output (option): 16 bit resolution, ±0.2% accuracy
  • Analog voltage range: 0/2–10V (max 10mA)
  • Analog current range: 0/4–20mA (max 500Ω load)
  • Serial interface option: RS485, RS422, or TTY
  • Protocol: DIN 66 019 / ISO 1745
  • Baud rates: 300, 1200, 2400, 4800, 9600, 19200
  • Data format: 1 start, 8 data, no parity, 1 stop
  • Power supply AC: 95–250V AC (~9 VA)
  • Power supply DC (option): 18–36V DC (~70mA)
  • Encoder power supply (AC version): 24V DC ±10%, max 125mA
  • Operating temperature: 0°C to +50°C
  • Storage temperature: -20°C to +70°C
  • Humidity: <80% non-condensing

Frequently asked questions

  • Q: Can ADP-010 485-00230 work with any SSI encoder?
    A: Yes. It accepts single-turn or multi-turn SSI signals with 10–25 bit resolution in binary or Gray code.
  • Q: What happens when the clock signal breaks in slave mode?
    A: The unit requires a minimum break of 500 µs between clock bursts for proper operation.
  • Q: Do I need external power for my encoder?
    A: No if you order the AC version. It provides 24V DC output for the encoder (max 125mA).
  • Q: Can I get both analog output and serial interface?
    A: Yes. You can add the 16-bit analog output and RS485/RS422/TTY interface as options.
  • Q: Is the front panel washable?
    A: The front meets IP54 rating, so it resists dust and water splashes. The rear connectors are IP20 only.
