Key Features

• Power Supply: Main supply: 24 VDC; Regulated outputs: 10 A or 5 VDC for kernel section.
• Compatibility: Specifically designed to work with the TMR5200 CPU.
• Installation: Requires removal of all kernels within the MicroNet TMR Kernel Power Supply module for replacement.
• Location Suitability: Can be used in:
  • Class I Locations
  • Division 2 Locations
  • Groups A, B, C, and D Locations
  • Non-hazardous Locations
• Health Monitoring: Single LED indicator on the front faceplate for module health. Fault LED indicates the status of 5V and 5V precharge functions.
• Kernel Sections: Contains three kernel sections (A-B-C), each housing one kernel power supply module. 5466-1049 is located in the first slot of the kernel sections.
• Certifications: CSA certification; CE (EMC) certification.

Technical Specifications

• Model: 5466-1049
• Power Input: 24 VDC
• Output Current: 10 A
• Output Voltage: 5 VDC
• CPU Compatibility: TMR5200
• Output Voltage Tolerance: 5 VDC ±5%
• Model: TMR Kernel PS
• Manual: 26167V1 and 26166V2
• Input Voltage Tolerance: 24 VDC ±10%
• Location Classifications:
  • Class I, Division 2
  • Groups A, B, C, and D
• LED Indicators: Health LED; Fault LED
• Operating Temperature: 0 to +55°C
• Weight: 22 kg (48 lbs) in Chassis
