Overview

The GE Fanuc IC660TBA103 Terminal Assembly, part of the Genius I/O series, provides reliable thermocouple-compatible inputs with robust isolation and efficient power management. Designed for harsh industrial environments, it supports various voltage types, offers compact dimensions, and ensures safe operation with high isolation ratings.

Technical Specifications

• Brand: GE Fanuc
• Model: IC660TBA103
• Series: Genius I/O
• Description: Terminal Assembly
• Block Type: 6 thermocouple-compatible inputs, three isolated groups of two
• Rated Voltage: 115 Volts AC / 125 Volts DC
• Power Supply Voltage: 93-132 Volts AC at 9 Watts / 105-145 Volts DC at 9 Watts
• Power Supply Dropout Time: 1 cycle (AC) / 10 milliseconds (DC)
• Frequency/Ripple: 47 to 63 Hertz / 10% maximum ripple
• Heat Dissipation (Max): 9 Watts
• Block to Block Isolation: 1500 Volts for 1 minute
• Group to Group Isolation: 300 Volts
• Dimensions (HxWxD): 224 x 88 x 100 millimeters (8.8 x 3.5 x 3.9 inches)
• Weight: 1.8 kg (4 pounds)
• Operating Temperature: 0 to 60°C (32 to 140°F)
• Storage Temperature: -40 to 100°C (-40 to 212°F)

  FAQ

  Q: What are the key differences of the "103" model in the Genius I/O series?
  A: The IC660TBA103 offers thermocouple compatibility with isolated input groups, providing greater flexibility for temperature measurements.

  Q: Can it handle high voltage fluctuations?
  A: Yes, the assembly supports a wide voltage range and is rated for 115V AC or 125V DC with quick recovery times.

  Q: What is the isolation rating of the IC660TBA103?
  A: It features 1500 Volts block-to-block isolation and 300 Volts group-to-group isolation, ensuring safe operation in industrial environments.

  Q: Is this terminal assembly suitable for extreme temperatures?
  A: Yes, it operates effectively in temperatures ranging from 0°C to 60°C (32°F to 140°F) and can be stored in conditions between -40°C and 100°C (-40°F to 212°F).
