6ES7326-2BF10-0AB0 Siemens Digital Output Module
Manufacturer:
Siemens
Product No.:
6ES7326-2BF10-0AB0
Condition:
In Stock
Product Type:
Digital Output Module
Product Origin:
DE
Weight:
330g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Supply Voltage
- Rated value (DC): 24 V; 1L+
- Reverse polarity protection: Yes
Load Voltage L+
- Rated value (DC): 24 V; 2L+, 3L+
- Reverse polarity protection: No
Input Current
| Source | Max Current |
|---|---|
| From supply voltage 1L+ | 100 mA |
| From load voltage 2L+ (without load) | 100 mA |
| From load voltage 3L+ (without load) | 100 mA |
| From backplane bus 5 V DC | 100 mA |
Power Loss
- Power loss, typical: 6 W
Digital Outputs
- Number of digital outputs: 10
- Short-circuit protection: Yes
Switching Capacity of the Outputs
- On lamp load, max: 5 W
Output Voltage
- For signal "1", min: L+ (-1.0 V)
Output Current
| Condition | Range |
|---|---|
| For signal "1" rated value | 2 A |
| For signal "1" permissible range for 0 to 40 °C, min | 7 mA |
| For signal "1" permissible range for 0 to 40 °C, max | 2.4 A |
| For signal "1" permissible range for 40 to 60 °C, min | 7 mA |
| For signal "1" permissible range for 40 to 60 °C, max | 2.4 A |
| For signal "0" residual current, max | 0.5 mA |
Switching Frequency
| Load Type | Max Frequency |
|---|---|
| Resistive load | 25 Hz |
| Inductive load | 25 Hz |
| Lamp load | 10 Hz |
Total Current of the Outputs (per group)
Horizontal Installation
- Up to 40 °C, max: 10 A
- Up to 60 °C, max: 6 A
Vertical Installation
- Up to 40 °C, max: 5 A
Cable Length
- Shielded, max: 1,000 m
- Unshielded, max: 600 m
Isolation
- Isolation tested with: 370V for 1 min
Connection Method
- Required front connector: 40-pin
Dimensions
- Width: 40 mm
- Height: 125 mm
- Depth: 120 mm
Weights
- Weight, approx.: 330 g
