6ES7331-1KF02-0AB0 Siemens Analog Input Module

In stock
Manufacturer:
Siemens
Product No.:
6ES7331-1KF02-0AB0
Condition:
In Stock
Product Type:
Analog Input Module
Product Origin:
DE
Weight:
250g
Shipping port:
Xiamen
Warranty:
12 months

UBEST – Trusted Global Automation Parts Supplier

We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.

About Us | Contact

Technical Specifications

Parameter Specification
Input Current From backplane bus 5 V DC, max. 90 mA
Power Loss Power loss, typ. 0.4 W
Analog Inputs Number of analog inputs 8
For Resistance Measurement 8
Permissible Input Voltage for Voltage Input (Destruction Limit), Max. 30 V; 12 V continuous, 30 V for max. 1 s
Permissible Input Current for Current Input (Destruction Limit), Max. 40 mA
Input Ranges (Rated Values), Voltages
  • 0 to +10 V: Yes
  • Input Resistance (0 to 10 V): 100 kΩ
  • 1 V to 5 V: Yes
  • Input Resistance (1 V to 5 V): 100 kΩ
  • 1 V to 10 V: No
  • -1 V to +1 V: Yes
  • Input Resistance (-1 V to +1 V): 100 kΩ
  • -10 V to +10 V: Yes
  • Input Resistance (-10 V to +10 V): 100 kΩ
  • -2.5 V to +2.5 V: No
  • -250 mV to +250 mV: No
  • -5 V to +5 V: Yes
  • Input Resistance (-5 V to +5 V): 100 kΩ
  • -50 mV to +50 mV: Yes
  • Input Resistance (-50 mV to +50 mV): 100 kΩ
  • -500 mV to +500 mV: Yes
  • Input Resistance (-500 mV to +500 mV): 100 kΩ
  • -80 mV to +80 mV: No
Input Ranges (Rated Values), Currents
  • 0 to 20 mA: Yes
  • Input Resistance (0 to 20 mA): 100 Ω
  • -10 mA to +10 mA: No
  • -20 mA to +20 mA: Yes
  • Input Resistance (-20 mA to +20 mA): 100 Ω
  • -3.2 mA to +3.2 mA: No
  • 4 mA to 20 mA: Yes
  • Input Resistance (4 mA to 20 mA): 100 Ω
Dimensions
  • Width: 40 mm
  • Height: 125 mm
  • Depth: 117 mm
Weight Approximately 250 g
