6ES7331-7KF02-0AB0 Siemens - Analog Input Module
Manufacturer:
Siemens
Product No.:
6ES7331-7KF02-0AB0
Condition:
In Stock
Product Type:
Analog Input Module
Product Origin:
DE
Weight:
250g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Siemens Product Information | |
|---|---|
| Article Number (Market Facing Number): | 6ES7331-7KF02-0AB0 |
Siemens Supply Voltage | |
|---|---|
| Load Voltage L+ | Rated value (DC): 24 V |
| Reverse Polarity Protection: | Yes |
Siemens Input Current | |
|---|---|
| From Load Voltage L+ (Without Load), Max.: | 30 mA |
| From Backplane Bus 5 V DC, Max.: | 50 mA |
Siemens Power Loss | |
|---|---|
| Power Loss, Typ.: | 1 W |
Siemens Analog Inputs | |
|---|---|
| Number of Analog Inputs: | 8 |
| For Resistance Measurement: | 4 |
| Permissible Input Voltage for Voltage Input (Destruction Limit), Max.: | 20 V continuous; 75 V for max. 1 s (mark to space ratio 1:20) |
| Permissible Input Current for Current Input (Destruction Limit), Max.: | 40 mA |
| Constant Measurement Current for Resistance-Type Transmitter, Typ.: | 1.67 mA |
Siemens Errors/Accuracies | |
|---|---|
| Operational Error Limit in Overall Temperature Range: | Voltage: ±1% (80 mV); ±0.6% (250 mV to 1 000 mV); ±0.8% (2.5 V to 10 V) Current: ±0.7% (3.2 to 20 mA) Resistance: ±0.7% (150, 300, 600 Ohm) Resistance Thermometer: ±0.7% (Pt100/Ni100); ±0.8% (Pt100 climate) Thermocouple: ±1.1% (Type E, J, K, L, N) |
| Basic Error Limit (Operational Limit at 25 °C): | Voltage: ±0.6% (80 mV); ±0.4% (250 mV to 1 000 mV); ±0.6% (2.5 V to 10 V) Current: ±0.5% (3.2 to 20 mA) Resistance: ±0.5% (150, 300, 600 Ohm) Resistance Thermometer: ±0.6% (Pt100/Ni100); ±0.6% (Pt100 climate) Thermocouple: ±0.7% (Type E, N, J, K, L) |
Siemens Isolation | |
|---|---|
| Isolation Tested With: | 500 V DC |
Siemens Dimensions | |
|---|---|
| Width: | 40 mm |
| Height: | 125 mm |
| Depth: | 117 mm |
Siemens Weights | |
|---|---|
| Weight, Approx.: | 250 g |
