6GK1571-0BA00-0AA0 Siemens PC Adapter
Manufacturer:
Siemens
Product No.:
6GK1571-0BA00-0AA0
Condition:
In Stock
Product Type:
PC Adapter
Product Origin:
DE
Weight:
365g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Transfer Rate
| Transfer Rate | At the 1st interface / according to PROFIBUS 9.6 kbit/s ... 12 Mbit/s |
Interfaces
| Number of Electrical Connections | At the 1st interface / according to PROFIBUS 1 |
| Number of Interfaces / according to USB | 1 |
| Type of Electrical Connection | At the 1st interface / according to PROFIBUS 9-pin Sub-D socket (RS 485) |
| Of the USB interface | Standard-B socket |
| Standard for Interfaces / USB 2.0 | Yes |
Supply Voltage, Current Consumption, Power Loss
| Type of Voltage / of the Supply Voltage | DC |
| Type of Voltage Supply / Optional External Power Supply | No |
| Supply Voltage | From USB 5 V |
| Note | Supply direct from USB |
| Relative Symmetrical Tolerance / at DC | At 5 V 5 % |
| Consumed Current | From USB 0.2 A |
| Power Loss [W] | 1 W |
Ambient Conditions
| Ambient Temperature | During operation 0 ... 60 °C |
| During Storage | -40 ... +70 °C |
| During Transport | -40 ... +70 °C |
| Relative Humidity / at 30 °C / During Operation / Maximum | 95 % |
| Protection Class IP | IP20 |
Design, Dimensions and Weights
| Module Format | USB V2.0 adapter |
| Width | 58 mm |
| Height | 26 mm |
| Depth | 105 mm |
| Net Weight | 0.365 kg |
| Fastening Method / 35 mm Top Hat DIN Rail Mounting | No |
