8 mm Proximity Transducer System 330102-00-17-50-11-CN
Manufacturer:
Bently Nevada
Product No.:
330102-00-17-50-11-CN
Condition:
In Stock
Product Type:
3300 XL 8 mm Proximity Transducer System
Product Origin:
USA
Weight:
320g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
🛠 Technical Specifications
Model Information
| Parameter | Specification |
|---|---|
| 🏢 Brand | Bently Nevada |
| 🔢 Model | 330102-00-17-50-11-CN |
| ⚙️ Series | 3300 XL |
| 🌍 Country of Origin | U.S.A. |
| 🔧 Mounting Type | 4-hole mounting base |
Performance & Specifications
| Parameter | Specification |
|---|---|
| 📏 Maximum Cable Length | 30 meters (standard configuration) |
| 🌡️ Temperature Range | -40°C to +85°C (-40°F to +185°F) |
| ⚡ Power Supply | 24 VDC (typical) |
| 🔌 Connector Type | 5-pin, gold-plated brass or beryllium copper |
| 📏 Measurement Range | 0 to 8 mm displacement |
| ⏱️ Response Time | 0.3 ms |
| 📏 Mounting Hole Diameter | 6.35 mm (1/4 inch) |
| 🔧 Mounting Depth | 17.5 mm |
| 🔊 Vibration Range | Suitable for high-frequency vibration applications (up to 10 kHz) |
| 🔧 Mounting Torque | 6.8 Nm (50 lb-in) |
Material & Construction
| Parameter | Specification |
|---|---|
| 🔧 Probe Tip Material | Polyphenylene sulfide (PPS) |
| 🔧 Probe Case Material | AISI 303 or 304 stainless steel (SST) |
Applications & Approvals
| Parameter | Specification |
|---|---|
| 🌍 Country of Origin | U.S.A. |
| 🌐 Agency Approvals | Country-specific approvals |
