900H32-0001 Honeywell | 32 Point Digital Output Module HC900
Manufacturer:
Honeywell
Product No.:
900H32-0001
Condition:
In Stock
Product Type:
Digital Output Module
Product Origin:
USA
Weight:
180g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Technical Specifications
| Specification | Value |
|---|---|
| Dimensions | 137mm H x 35.6mm W (5.4” H x 1.4” W) |
| Weight | 180g |
| Outputs per Module | 32 (current sourcing, high side) |
| Note | Outputs 17 through 32 may not be used for TPO, PPO, or TPSC output types. |
| Galvanic Isolation | 2 groups of 16 outputs |
| Operating Voltage | 10.5 to 32 VDC |
| Output Type | High side driver |
| Peak Voltage | 32 VDC |
| AC Frequency | N/A |
| ON Voltage Drop | 0.15 VDC @ 0.5 A load |
| Overload Protection | Active Current Limiting integrated into output driver as 4 groups of 8 channels each. |
| Maximum Load Current | 0.5 A per point, 12 A max. per module |
| Maximum Leakage Current | 0.15mA @ 32 VDC |
| Maximum Inrush Current | 2 A for 10 ms |
| Minimum Load | 0.0 mA |
| Response Time (OFF to ON) | 6 ms |
| Response Time (ON to OFF) | 6 ms |
| Fuses | Electronic limiting |
| Power Supply Loading | 5V; 235mA |
