Bently Nevada 9200 Seismoprobe: Advanced Two-Wire Velocity Sensing

The Bently Nevada 9200 two-wire velocity transducer delivers precise vibration monitoring for industrial applications. This seismoprobe transducer combines rugged construction with reliable performance in demanding environments. We provide worldwide shipping through FedEx, UPS, and DHL express services.

Product Identification & Configuration

• Manufacturer: Bently Nevada
• Complete Part Number:9200-03-24-10-00
• Product Model: Two-Wire Velocity Seismoprobe Transducer
• Product Condition: New & Original Factory Packaging
• Quality Assurance: 12 Months Manufacturer Warranty

Configuration Breakdown Structure

• Base Platform: 9200 Two-wire Transducer Series
• Mounting Angle [03]: 90° ±2.5° at 4.5 Hz Minimum
• Cable Length [24]: 24 Feet Integrated Cable Assembly
• Mounting Base [10]: Circular Design with M10X1 Thread
• Certification [00]: Standard Model, No Special Approvals

Technical Performance Specifications

• Velocity Sensitivity: 20 mV/mm/s ±5% Calibration Accuracy
• Measurement Range: 25 mm/s Maximum Velocity Capacity
• Displacement Limit: 2.54 mm Peak-to-Peak Maximum
• Electrical Resistance: 1.25 kΩ Coil Resistance ±5% Tolerance
• Coil Inductance: 125 mH Typical Locked Coil Value
• Calibration Load: 10 kΩ Standard Termination Resistance
• Temperature Coefficient: 0.2% per °C Sensitivity Variation
• Operating Temperature: -29°C to +121°C Standard Range
• Extended Temperature: -29°C to +204°C Enhanced Version
• Environmental Rating: Dust and Moisture Resistant Design
• Humidity Tolerance: 95% Non-Condensing Operation
• Case Material: Anodized Aluminum A204 Construction
• Gasket Material: Neoprene Sealing for Protection
• Physical Dimensions: 102mm Height × 41mm Diameter
• Unit Weight: 300 Grams Typical Transducer Mass
• Frequency Response: Optimized for Industrial Vibration

Advanced Product Features

• Two-Wire Simplicity: Reduced installation complexity and cost
• Velocity Output: Direct measurement of vibration velocity
• Robust Construction: Anodized aluminum housing for durability
• Wide Temperature Range: Performs in extreme environments
• Environmental Protection: Resists dust and moisture ingress
• Precision Calibration: Factory calibrated for accurate measurements
• Flexible Mounting: Circular base with M10X1 threaded stud
• Integrated Cable: 24-foot cable for installation flexibility

Package Contents

• One Bently Nevada 9200 Seismoprobe Transducer
• Integrated 24-foot Measurement Cable
• Circular Mounting Base with M10X1 Thread
• Factory Calibration Documentation
• Installation and Operation Manual

Installation & Application

• Mount at 90° angle for optimal performance
• Ensure minimum 4.5 Hz operating frequency
• Use 10 kΩ termination for accurate sensitivity
• Maintain proper orientation during installation
• Verify environmental conditions within specifications

Service & Support

• Warranty Protection: 12 Months Comprehensive Coverage
• Shipping Methods: FedEx, UPS, DHL Express Options
• Global Distribution: International Shipping Available
• Technical Assistance: Expert Support Provided

Professional Technical FAQs

• What advantages does the two-wire design offer over traditional sensors?
  The two-wire configuration simplifies installation by reducing wiring complexity. It provides both power and signal transmission through the same pair of wires.
• How does the mounting angle affect measurement accuracy?
  The transducer is calibrated for 90° mounting with ±2.5° tolerance. Proper orientation ensures the specified sensitivity of 20 mV/mm/s is maintained.
• Can this transducer operate in high-temperature environments?
  The standard model operates from -29°C to +121°C, while the enhanced version handles temperatures up to 204°C for extreme applications.
• What is the significance of the velocity range specification?
  The 25 mm/s velocity range indicates the maximum vibration level the transducer can accurately measure without signal distortion or damage.
• How does the temperature coefficient affect long-term performance?
  The 0.2% per °C temperature coefficient ensures predictable performance variations across the operating temperature range.
