AAT145-S50 Yokogawa TC/mV Input Module
Manufacturer:
Yokogawa
Product No.:
AAT145-S50
Condition:
In Stock
Product Type:
TC/mV Input Module
Product Origin:
JP
Weight:
500g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Technical Specifications Overview
Input Specifications
| Type | Supported Types and Ranges |
|---|---|
| Thermocouple | B, R, S, K, E, J, T, N, W - ±100mV |
| mV | ±1000mV |
Measurement and Accuracy
| Feature | Specification |
|---|---|
| Measurement Accuracy | ±0.1% of Full Scale (F.S.) |
| Cold Junction Compensation | Automatic |
| Input Impedance | 1MΩ or higher |
Electrical Specifications
| Feature | Specification |
|---|---|
Isolation Voltage |
500VDC |
| Power Supply | 24VDC |
Environmental and Physical Specifications
| Feature | Specification |
|---|---|
| Operating Temperature | 0 to 50°C |
| Dimensions (W x H x D) | 35 x 130 x 149 mm |
| Weight | Approx. 0.5 kg |
Suffix Descriptions
| Suffix | Description |
|---|---|
| -S | Signal type: Standard (TC and mV) |
| 50 | Input range: ±50 mV |
