ABB PM891K02 3BSE053242R1 | AC 800M Controllers
Manufacturer:
ABB
Product No.:
PM891K02
Condition:
In Stock
Product Type:
AC 800M Controllers
Product Origin:
DE
Weight:
4000g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
General Information
| Article Number | 3BSE053242R1 (PM891K02) |
|---|---|
| Redundancy | Yes |
| High Integrity | No |
| Clock Frequency | 450 MHz |
| Performance, 1000 boolean operations | 0.043 ms |
| Performance | 0.043 ms |
| Memory | 256 MB |
| RAM Available for Application | 208.985 MB |
| Flash Memory for Storage | Yes |
Detailed Data
| Processor Type | MPC8270 |
|---|---|
| Switch Over Time in Redundant Configuration | Max 10 ms |
| Number of Applications per Controller | 32 |
| Number of Programs per Application | 64 |
| Number of Diagrams per Application | 128 |
| Number of Tasks per Controller | 32 |
| Number of Different Cycle Times | 32 |
| Cycle Time per Application Programs | Down to 1 ms |
| Flash PROM for Firmware Storage | 16 MB |
| Power Supply | 24 V DC (19.2-30 V DC) |
| Power Consumption +24 V Typ/Max | 660/750 mA |
| Power Dissipation | 15.8 W (18 W max) |
| Redundant Power Supply Status Input | Yes |
| Built-in Back-up Battery | No |
| Clock Synchronization | 1 ms between AC800M controllers by CNCP protocol |
| Event Queue in Controller per OPC Client | Up to 3000 events |
| AC 800M Transmission Speed to OPC Server | 36-86 events/sec, 113-143 data messages/sec |
| Communication Modules on CEX Bus | 12 |
| Supply Current on CEX Bus | Max 2.4 A |
| I/O Clusters on Modulebus with Non-Redundant CPU | 0 electrical + 7 optical |
| I/O Clusters on Modulebus with Redundant CPU | 0 electrical + 7 optical |
| I/O Capacity on Modulebus | Max 84 modules |
| Modulebus Scan Rate | 0 - 100 ms (actual time depending on number of I/O modules) |
| Supply Current on Electrical Modulebus | 24 V : max 1.0 A |
| 5 V : max 1.5 A | |
| Ethernet Channels | 2 |
| Ethernet Interface | 10/100 Mbit/s |
| Control Network Protocol | MMS (Manufacturing Message Service) and IAC (Inter Application Communication) |
| Recommended Control Network Backbone | 100 Mbit/s switched Ethernet |
| Real-time Clock Stability | 50 ppm (approx 0.5h / year) |
| RS-232C Interface | 1 for service tool (COM 4) |
| RS-232C Interface (COM3) (Non-Redundant Only) | Not supported |
| RS-232C Interface (COM4) (Non-Redundant Only) | RS-232C, 9600 baud, RJ-45 female (8-pole), opto-isolated, no RTS-CTS support |
Environment and Certification
| Temperature, Operating | +5 to +55 °C (+41 to +131 °F) |
|---|---|
| Temperature, Storage | -40 to +70 °C (-40 to +158 °F) |
| Temperature Changes | 3 °C/minutes according to IEC/EN 61131-2 |
| Pollution Degree | Degree 2 according to IEC/EN 61131-2 |
| Corrosion Protection | G3 compliant to ISA 71.04 |
| Relative Humidity | 5 to 95 %, non-condensing |
| Emitted Noise | - |
| Vibration | 10 < f < 50 Hz: 0.0375 mm amplitude |
| 50 < f < 150 Hz: 0.5 g acceleration | |
| 5 < f < 500 Hz: 0.2 g acceleration | |
| Rated Isolation Voltage | 50 V |
| Dielectric Test Voltage | 500 V a.c. |
| Protection Class | IP 20 according to EN 60529, IEC 529 |
| Altitude | 2000 m (6562 ft) according to IEC/EN 61131-2 |
| Emission & Immunity | EN 61000-6-4, EN 61000-6-2 |
| Environmental Conditions | Industrial |
| CE Mark | Yes |
| Electrical Safety | EN 50178, IEC 61131-2, UL 61010-1, UL 61010-2-201 |
| Hazardous Location | UL 60079-15, cULus Class 1, Zone 2, AEx nA IIC T4, ExnA IIC T4Gc X |
| Marine Certificates | ABS, BV, DNV-GL, LR |
| TUV Approval | No |
| RoHS Compliance | EN 50581:2012 |
| WEEE Compliance | DIRECTIVE/2012/19/EU |
Dimensions
| Width | 174 mm (6.85 in.) |
|---|---|
| Height | 186 mm (7.32 in.) |
| Depth | 94 mm (3.70 in.) |
| Weight (Including Base) | K01: 1600 g (3.5 lbs) |
| K02: 4000 g (8.8 lbs) |
