ACS580-01-12A7-4 ABB ACS580 AC Drive
Manufacturer:
ABB
Product No.:
ACS580-01-12A7-4
Condition:
In Stock
Product Type:
AC Drive
Product Origin:
SE
Weight:
4600g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Technical Specifications
Power and Current Ratings
| Rated Power (Pn) | 5.5 kW |
| Rated Current (In) | 12.6 A |
| Output Current for Heavy-Duty Use (IHD) | 9.4 A |
| Output Current for Light-Overload Use (ILD) | 12.0 A |
| Output Power for Heavy-Duty Use (PHD) | 4.0 kW |
| Output Power for Light-Overload Use (PLD) | 5.5 kW |
Electrical Specifications
| Input Voltage (U in) | 380 - 480 V |
| Frequency | 47.5 - 63 Hz |
| Apparent Power Output | 8.7 kVA |
| Efficiency Level | IE2 |
| Standby Loss | 14 W |
Environmental Specifications
| Operating Temperature Range | -15 °C to 40 °C |
| Altitude | Up to 1000 m |
Dimensions and Weight
| Product Net Dimensions (W x H x D) | 125 mm x 373 mm x 223 mm |
| Product Net Weight | 4.6 kg |
Enclosure and Protection
| Degree of Protection | IP21 (standard), with IP55 and flange mounting options available. |
| Enclosure Type | NEMA Type 1, suitable for wall-mounted installations. |
Communication and Interface
| Communication Protocols Supported | CAN, DeviceNet, EtherNet/IP, MODBUS, PROFIBUS, PROFINET IO, TCP/IP |
| Number of Hardware Interfaces | Analog Inputs: 2 Analog Outputs: 2 Digital In/Outputs: 6 / 3 USB Ports: 1 RS-485 Ports: 1 |
