ACS880-04-583A-5 ABB - Frequency converter
Manufacturer:
ABB
Product No.:
ACS880-04-583A-5
Condition:
In Stock
Product Type:
Frequency converter
Product Origin:
Finland
Weight:
165000g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
ABB ACS880-04-583A-5 Frequency Converter Specifications
General Information
| Feature | Specification |
|---|---|
| Global Commercial Alias | ACS880-04-583A-5 |
| Product ID | 3AUA0000139077 |
| Country of Origin | Finland |
| Customs Tariff Number | 85044086 |
| HS Code | 850440 |
Dimensions
| Dimension | Metric | Imperial |
|---|---|---|
| Net Weight | 165 kg | 363.763 lb |
| Net Depth / Length | 506 mm | 19.921 in |
| Net Height | 1541 mm | 60.669 in |
| Net Width | 350 mm | 13.780 in |
Technical Specifications
| Feature | Specification |
|---|---|
| Number of Phases | 3 |
| Degree of Protection | IP20 |
| Input Voltage (Uin) | 380 ... 500 V |
| Output Current, Heavy-Duty Use (IHD) | 414 A |
| Output Power, Heavy-Duty Use (PHD) | 250 kW |
| Output Power, Light-Overload Use (PLD) | 400 kW |
| Output Power, Normal Use (Pn) | 400 kW |
| Apparent Power Output | 505 kVA |
| Efficiency Level | IE2 |
| Standby Loss | 427 W |
| Frequency (f) | 47.5 ... 63 Hz |
| Frame Size | R10 |
| Operating Temperature Range | Maximum 40 °C |
Connectivity and Interfaces
| Feature | Specification |
|---|---|
| Communication Protocols | CAN, DeviceNet, Ethernet/IP, MODBUS, PROFIsafe, PROFIBUS, PROFINET IO |
| Analog Inputs | 2 |
| Analog Outputs | 2 |
| Digital Inputs/Outputs | 6 / 2 |
| USB Ports | 1 |
| RS-485 Interfaces | 1 |
Environmental and Safety
| Feature | Specification |
|---|---|
| Altitude | Up to 4000 m |
| Operating Humidity (RH) | 5% ... 95% |
| Sound Level | 72 dB(A) |
| WEEE Category | 4. Large Equipment |
| Battery Information | Lithium Coin, CR2032, 220 mAh, 3 V, 2 pcs, 6 g |
