ADV161-P00 Yokogawa ADV161 Digital Input Module
Manufacturer:
Yokogawa
Product No.:
ADV161-P00
Condition:
In Stock
Product Type:
Digital Input Module
Product Origin:
JP
Weight:
300g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Item Specifications
| Parameter | Value |
|---|---|
| Model | ADV161-P00 |
| Number of input channels | 64 |
| Rated input voltage | 24 V DC (sink/source) |
| Input ON voltage | 20 to 26.4 V DC |
| Input OFF voltage | 5.0 V DC or less |
| Input current (at rated input voltage) | 2.5 mA ±20 % / channel |
| Maximum allowable input voltage | 30.0 V DC |
| Withstanding voltage | Between input signal and system: 2 kV AC, For 1 minute Between commons: 500 V AC, For 1 minute, common every 16-channel |
| Functions | Status input: Function for detecting ON/OFF status Pushbutton input: Function for counting the pushbutton edges |
| Input response time | 8 ms or less (for status input) |
| Minimum ON detection time | 20 ms (for pushbutton input) |
| Maximum ON/OFF cycle | 25 Hz (for pushbutton input) |
| Maximum current consumption | 550 mA (5 V DC) |
| Weight | Approx. 0.30 kg |
| External connection | Dedicated cable (AKB337), MIL connector cable |
| Dimensions | 130 mm x 119.9 mm x 32.8 mm |
| Weight | 0.3 kg |
MODELS AND SUFFIX CODES
| Model | Description |
|---|---|
| ADV161-P00 |
ADV161: Digital Input Module (64-channel, 24 V DC, Isolated) -P: With push button input -0: Without status display; with no explosion protection -0: Basic type |
