Item Specifications

• Physical layer interface: IEEE802.3 10BASE-T
• Connection method: Point-to-point
• Connector: RJ-45
• Transmission method: Half-duplex
• Transmission speed: 10 Mbps
• Transmission route: 100 ohm twisted-pair cable (not shielded)
• Transmission distance: 1 segment, 100 m (in between FCS and subsystems, or HUB and subsystems)
• Installation method: Mounted on ANB10, ANB11, ANR10, AFF50, AFV10, AFV30, or AFV40
• No. of ports: One port
• Media access control: CSMA/CD
• Communication functions: Communications with FA-M3, Modbus, MELSEC, YFGW, DARWIN/DAQSTATION, and PLC-5/SLC500
• Current consumption: 0.5 A
• Weight: 0.3 kg
• Dimension: 130mm x 125.5mm x 32.8mm

Model and Suffix Codes

Model: ALE111 Ethernet Communication Module

• Suffix Codes:
• -S: Standard Type
• -0: With no explosion protection
• -1: With ISA Standard G3 option
