1756-EN2TR ControlLogix Ethernet Module

Description

The 1756-EN2TR is a dual-port Ethernet communication module designed for ControlLogix systems. It supports robust and high-speed network connectivity for industrial automation applications, providing reliable communication and efficient data exchange.

Features

• Communications Ports:
  • 2 x Ethernet RJ-45 ports
  • 1 x USB port (programming only)
• Communications Protocols:
  • EtherNet/IP
  • EtherNet/OCPP
• Communication Port Speed: Maximum 100 Mbit/s

Specifications

• Operating Temperature:
  • Maximum: 60 °C
  • Minimum: 0 °C
• Storage Temperature:
  • Maximum: 85 °C
  • Minimum: -40 °C
• Relative Humidity: Up to 95% non-condensing.
• Vibration Resistance:
  • Acceleration: 2 m/s²
  • Frequency: Up to 500 Hz
• Standards Compliance:
  • IEC 60068-2-1
  • IEC 60068-2-14
  • IEC 60068-2-2
  • IEC 60068-2-27
  • IEC 60068-2-30
  • IEC 60068-2-6
  • IEC 61000-4-2
  • IEC 61000-4-3
  • IEC 61000-4-4
  • IEC 61000-4-5
  • IEC 61000-4-6
  • IEC 61000-6-4

Certifications

• CE
• KC (KCC)
• RCM
• ODVA - EtherNet/IP
