Allen-Bradley 1756HP-TIME GPS Time and Position Services Module
Manufacturer:
Allen-Bradley
Product No.:
1756HP-TIME
Condition:
In Stock
Product Type:
Time and Position Services Module
Product Origin:
USA
Weight:
200g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Overview
The Allen-Bradley / Rockwell Automation 1756HP-TIME is a GPS Time and Position Services Module for the ControlLogix platform. It uses GPS technology to provide accurate time synchronization and supports multiple time sources and protocols, including:
- Global Positioning System (GPS)
- Coordinated Universal Time (UTC)
- IRIG-B-122
- Precision Time Protocol (PTP)
- Network Time Protocol (NTP)
The module also provides GPS position information, including:
- X, Y, Z Cartesian ECEF (Earth-Centered, Earth-Fixed) coordinates
- Latitude, Longitude, and Altitude (LLA)
- X, Y, Z Cartesian ECEF and ENU (East-North-Up) velocities
The 1756HP-TIME is suitable for applications requiring precise time synchronization and location information, such as:
- Power grids
- Transportation
- Public safety
- Finance
- Manufacturing
Technical Specifications
| Feature | Value |
|---|---|
| Module Type | ControlLogix Time Synchronization Module |
| Series | A |
| Firmware Version | 3.001 |
| Power Supply | 24V DC |
| Power Consumption | 1.5W |
| Operating Temperature | -40°C to 70°C |
| Storage Temperature | -40°C to 85°C |
| Humidity | 5% to 95% (non-condensing) |
| Vibration | 5g RMS, 10 to 500 Hz |
| Shock | 30g, 11 ms |
| Dimensions | 90 x 30 x 30 mm |
| Weight | 0.2 kg |
| Connection | ControlLogix backplane |
| Time Synchronization Accuracy | < 10 microseconds |
| Position Accuracy | < 2.5 meters (with external antenna) |
Features
- Provides accurate time synchronization, supporting multiple time sources and protocols
- Offers GPS position information, including X, Y, Z Cartesian ECEF coordinates, latitude, longitude, altitude, and X, Y, Z Cartesian ECEF and ENU velocities
- Supports redundant configuration
- Configurable and monitorable via web interface
- Compliant with RoHS directive
Applications
- Power grids
- Transportation
- Public safety
- Finance
- Manufacturing
