🔧 Manufacturer & Brand

Manufacturer: Rockwell Automation

Brand: Allen-Bradley

Series: Stratix 5700

Part Number / Catalog No.:1783-BMS10CGP

🔋 Electrical Specifications

Power Supply: 12…48V DC

Power Dissipation: 20 W

Input Voltage: 12 to 48 Volts DC

Alarm Relay: 1 A @ 30V DC or 0.5 A @ 48V DC

📡 Connectivity & Ports

No. of Gigabit Ports: Two (2)

No. of Fast Ethernet Ports: Eight (8)

Total Ports: Ten (10)

RJ45 Ports: 8

Combo Ports: 2

⚙️ Installation & Wiring

Wire Size, Ground Connection: 4.0 mm² (12 AWG) min, stranded copper wire

Wire Size, DC Power Connection: 0.5…0.8 mm² (20…18 AWG), stranded copper wire

Wire Size, Ethernet Connection: RJ45 connector, Cat 5e or Cat 5 cable

DLR: Yes

📈 Additional Parameters

CIP Sync: Yes

Operating Temperature: -40 to 70°C

Mounting: DIN Rail or Panel Mount

Weight: 2.6 lbs (1.18 kg)
