Allen-Bradley 2711C-T6T PanelView 600 Touch Display - 6" Color HMI with Durable Design

Industrial-Grade Touchscreen Solution

The Allen-Bradley 2711C-T6T is a rugged 6-inch color touchscreen from the PanelView Component series. Perfect for factory automation with its 40,000-hour backlight and IP65-rated enclosure.

Top Features

• Crisp 6" display (320 x 240 resolution)
• Long-life backlight (40,000+ hours)
• Wide voltage input (18-30V DC)
• Multiple enclosure ratings (NEMA 4X/IP65)
• Low power (only 5W consumption)

Technical Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 2711C-T6T
• Series: PanelView C600
• Display: 6" color (115 x 86mm viewing area)
• Touch Type: Resistive touchscreen
• Power: 24V DC (18-30V range)
• Protection: NEMA 12/13/4X, IP54/IP65
• Dimensions: 6.0 x 8.23 x 2.25 inches
• Weight: 0.72 kg (1.59 lbs)

Installation & Compatibility

• Works with Internet Explorer 7/8 and Firefox 3.0
• Panel-mount design for easy installation
• Compact size fits space-limited applications

Durability Features

• Industrial-strength construction
• Withstands dust, moisture, and oils
• 32 BTU/hr heat dissipation

5 Key Questions

• Q: Is the touchscreen replaceable?
  A: No, the display and touchscreen are one sealed unit.
• Q: What's the operating temperature range?
  A: 0-50°C (32-122°F) standard operation.
• Q: Can I use this outdoors?
  A: Yes, with proper NEMA 4X/IP65 enclosure protection.
• Q: Is the backlight adjustable?
  A: Yes, brightness can be adjusted through software.
• Q: What communication protocols are supported?
  A: Depends on the connected controller - consult manual.

Get your 2711C-T6T HMI today - reliable touch control for industrial applications!
