Allen-Bradley PowerFlex 40 22B-B012C104: Compact 3HP VFD with IP66 Protection & Sensorless Vector Control

Technical Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 22B-B012C104 | Series: PowerFlex 40
• Input Voltage: 200-240V AC ±10%
• Output: 12A, 3HP (2.2kW)
• Frequency Response: 0.5-400 Hz adjustable
• Operating Temp: -10°C to 50°C (14°F to 122°F)
• Housing: IP66, NEMA/UL Type 4X (corrosion-resistant)
• Communication: RS-485 + Bluetooth® (with module)
• Frame Size: B (87.4mm/3.44")
• Weight: 2.2 kg (4.9 lbs)

Installation Guide

• Panel mount in Size B frames only
• Vertical mounting (±10° tolerance)
• Minimum 100mm clearance on sides
• Requires 3-phase power connection

Compatibility

• Works with all 3-phase AC motors
• Integrates with Allen-Bradley PLC systems
• DSI protocol for peripheral devices

Certifications & Warranty

• Certified: UL, cUL, NEMA 4X, IP66
• 12-month warranty against defects
• Compliance: RoHS, WEEE

Shipping Details

• Carriers: FedEx, UPS, DHL
• Delivery: 2-5 business days (US/EU)
• Package: Drive unit, manual, mounting kit

Diagnostics & FAQ

• Q: Single-phase input possible?
  A: No, 3-phase input only
• Q: Bluetooth included?
  A: Requires 22-WIM module
• Q: Overload protection?
  A: Yes, electronic motor overload
• LED fault codes with troubleshooting guide
