Schneider ATV610C11N4 - Industrial-Grade Variable Frequency Drive

Drive Performance

• 110kW (150HP) normal duty capacity
• Wide voltage range: 380-460V ±10%
• Advanced motor control profiles (VT/CT)
• 0.1-500Hz output frequency range

Technical Specifications

• Model: ATV610C11N4 (Altivar 610 series)
• Power Ratings:
  • Normal duty: 110kW/201A @380V
  • Heavy duty: 90kW/170A @380V
• Motor Compatibility: Asynchronous/Synchronous
• Control Features:
  • 16 preset speeds
  • Adjustable switching frequency (1-8kHz)
  • Motor slip compensation
• Protections:
  • Overcurrent/Overvoltage
  • Short-circuit/Thermal
  • Phase loss/Motor overload

Connectivity & I/O

• Communication:
  • Modbus RTU via RS485
  • 3 expansion card slots
• Analog Inputs: 3 (0-10V/0-20mA)
• Digital Inputs: 6 (24VDC)
• Relay Outputs: 3 (3A@250VAC)

Physical Characteristics

• Dimensions: 300x850x375mm
• Weight: 85.5kg
• Mounting: Cabinet (IP20)
• Cooling: Forced convection

Environmental Ratings

• Temperature: -15°C to +45°C
• Humidity: 5-95% non-condensing
• Altitude: ≤1000m
• Noise: 76dB

Certifications

• CE Marked
• IEC 61800-3 (C3)
• IEC 61800-5-1

Package Includes

• ATV610C11N4 drive unit
• Installation manual
• 12-month warranty

Technical FAQ

• Q: What's the difference between normal/heavy duty?
  A: Heavy duty has lower ratings for demanding applications
• Q: Can I add communication protocols?
  A: Yes, via optional expansion cards
• Q: What cable sizes are supported?
  A: Power: 50-120mm², Control: 0.5-1.5mm²
• Q: Is braking resistor supported?
  A: Yes, via DC injection braking
• Q: What's the warranty period?
  A: 12 months from date of purchase

Optimize your motor control with the Schneider ATV610C11N4 - precision and reliability for industrial applications!
