Schneider ATV610D22N4 - Compact Power for Precise Motor Control

Drive Performance Highlights

• 22kW (30HP) normal duty capacity
• Ultra-wide 0.1-500Hz frequency range
• Dual power modes: Normal/Heavy Duty
• Only 65dB operation noise

Key Specifications

• Output Current: 46.3A (normal), 39.2A (heavy)
• Voltage Range: 380-460V ±10%
• Switching Frequency: 2-12kHz adjustable
• Dimensions: 211x495x232mm (13.5kg)

Smart Control Features

• 16 programmable preset speeds
• Built-in Modbus RTU communication
• 3 expansion slots for I/O options
• Auto motor slip compensation

Industrial Toughness

• Works in -15°C to +45°C temperatures
• Vibration-resistant cabinet mounting
• Integrated EMC filtering
• IP20 protection rating

What You Receive

• ATV610D22N4 drive unit
• Mounting hardware
• Quick-start guide
• 12-month warranty

Fast Shipping Options

• FedEx Priority (2-3 business days)
• UPS Ground/Air
• DHL Express Worldwide
• Real-time tracking included

Common Questions

• Q: What motors work with this drive?
  A: Compatible with most 3-phase motors 22kW and below
• Q: How many I/O points does it have?
  A: 6 digital inputs, 3 analog inputs, 3 relays
• Q: Can I monitor temperature?
  A: Yes, via dedicated sensor inputs
• Q: What maintenance is needed?
  A: Just annual cleaning of cooling vents
• Q: Is technical support available?
  A: 24/7 online support included

Upgrade to the ATV610D22N4 - big performance in a compact package!
