ATV610U07N4 Variable Speed Drive: Smart Motor Control for Pumps, Fans & Conveyors

Core Innovation

Control motors precisely with Schneider's Altivar 610 ATV610U07N4. This compact VSD saves energy in pumps, fans, and compressors.

Top Features

• ⚡ 0.75kW normal duty (1HP) motor power
• 📶 Built-in Modbus RTU communication
• 🌡️ Handles -15°C to 60°C temperatures
• 🔧 16 preset speeds for quick setup
• 🛡️ Integrated EMC filter (IEC 61800-3 C3)

Technical Specifications

• Power Range: 0.37-0.75kW (heavy/normal duty)
• Voltage: 380-460V ±10% 3-phase
• Frequency: 0.1-500Hz output (0.1Hz resolution)
• Switching: 2-12kHz adjustable (4kHz default)
• I/O:6 DI | 3 AI | 2 AO | 3 RO
• Altitude: 1000m (4800m with derating)

Smart Connectivity

• RJ45 port for Modbus RTU (4.8-38.4 kbit/s)
• Slot A for I/O/relay/communication cards
• Dual-color LEDs for real-time diagnostics

Industrial Tough

• ✅ IP20 protection against dust
• ✅ 55dB low-noise operation
• ✅ Vertical mounting (±10° tolerance)
• ✅ 19-23W power dissipation

Warranty & Delivery

• 12-month warranty
• Free global shipping: FedEx/UPS/DHL
• Dimensions: 145x297x203mm (3.135kg)

FAQ

• Q: Can it run 24/7?
  A: Yes, rated for continuous operation.
• Q: Max cable length for motors?
  A: 100m shielded (50m unshielded).
• Q: Braking resistor support?
  A: Yes, through optional modules.
• Q: Programming software?
  A: Free SoMove software available.
• Q: Surge protection?
  A: Built-in against 600V spikes.
