BC810K02 ABB | CEX-bus Interconnection Unit
Manufacturer:
ABB
Product No.:
BC810K02
Condition:
In Stock
Product Type:
CEX-bus Interconnection Unit
Product Origin:
Switzerland
Weight:
1500g
Shipping port:
Xiamen
Warranty:
12 months
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
🌐 Overview
BC810 includes a baseplate (TP857) and a power supply/logic board for CEX-Bus connections and power management.
🔧 Compatibility
The BC810 is compatible with the following units:
♻️ Redundancy and Replacement
Supports online CPU replacement and ensures CEX-Bus traffic continues in fully redundant setups.
🖧 CEX-Bus Functionality
Divides CEX-Bus into segments for enhanced system availability and redundancy.
✨ Features and Benefits
- Redundant communication support
- Online CPU replacement
- External power supply
- Hot swap capability
📦 Kit Components
Includes 2 BC810 units, 2 TP857 baseplates, 1 TK851 interconnection cable, and 2 TB850 terminators.
📄 General Information
- Article Number:3BSE031155R1
- Redundancy: Yes
- High Integrity: Yes
- Hot Swap: Supported
⚡ Detailed Data
- Power Supply: 24 V DC (19.2-30 V)
- Power Consumption: 50 mA typical
- Power Dissipation: 1.2 W typical
🌡 Environment & Certification
- Operating Temp: +5 to +55 °C
- Storage Temp: -40 to +70 °C
- Humidity: 5%-95%, non-condensing
- Protection Class: IP20
📏 Dimensions
- Width: 59 mm
- Height: 185 mm
- Depth: 127.5 mm
- Weight: 1.5 kg (including base)
