Description

The Bently Nevada 177230-01-02-05 model Seismic Transmitter is a versatile component designed to integrate seamlessly into your programmable logic controller (PLC) or control system for plant asset condition monitoring. With its simple design, it reduces training, maintenance, and service costs while enhancing the management of downtime and maintenance planning, ultimately helping to prevent catastrophic failures of machinery assets.

Functionality

• Measuring and Transmitting Vibration: This transmitter is utilized for measuring and transmitting mechanical vibration signals, facilitating efficient monitoring of machinery health.
• Analog Signal Conversion: It converts analog vibration signals received from velocity sensors into standard 4-20mA current signal outputs, ensuring compatibility with various control systems and monitoring solutions.

Technical Specifications

• Model: 177230-01-02-05
• Operating Voltage: 24 VDC
• Output Signal: 4-20mA
• Measurement Range: 0-50 mm/s (customizable for other ranges as needed)
• Accuracy: ±1% full scale
• Frequency Response: 2-1000 Hz
• Operating Temperature: -40°C to 85°C
• Protection Rating: IP65

Suffix Code:

• 177230: 177230 Seismic Transmitter
• -01: Measurement Range=0 – 25.4 mm/s (0 – 1.0 in/s)
• -02: Frequency=3 Hz to 1 kHz (180 to 60 kcpm) peak
• -05: Multiple Approvals (CSA/NRTL/C, ATEX/IECEx)

Dimensions:

• Diameter: 25.4 mm (1.00 in)
• Height: 66.0 mm (2.60 in)

Weight:

• 131 g (4.62 oz), typical
