Bently Nevada 3300 NSv Proximity Probes – precision for harsh environments

Complete suffix information – 330910‑14‑19‑10‑02‑00

• Model 330910 : 3300 NSv probe, M10x1 thread, stainless steel armor
• -14 unthreaded length : 140 mm (extends mounting flexibility)
• -19 overall case length : 190 mm
• -10 total length : 1.0 meter (39 inches) integrated cable
• -02 connector & cable : miniature coaxial ClickLoc™, standard 75 Ω FEP cable
• -00 agency approval : not required (standard industrial)

Core technical specifications

• brand & model : Bently Nevada 3300 NSv Proximity Probe
• linear range : 1.5 mm (60 mils) from 0.25 mm to 1.75 mm gap
• incremental scale factor (ISF) : 7.87 V/mm (200 mV/mil) ±12.5%/‑20% incl. interchangeability error
• deviation from straight line (DSL) : less than ±0.06 mm (±2.3 mils)
• frequency response : 0 Hz … 10 kHz (+0/‑3 dB) with up to 305 m field wiring
• probe DC resistance (1.0 m length) : 4.2 ±0.5 Ω (center to outer conductor)
• extension cable data : center cond. 0.220 Ω/m, shield 0.066 Ω/m, capacitance 69.9 pF/m
• temperature range : operating/storage –52 °C … +177 °C (–62 °F … +351 °F)
• probe tip material : polyphenylene sulfide (PPS) — excellent chemical resistance
• case material : AISI 304 stainless steel
• minimum target size : 8.9 mm dia. (recommended ≥13 mm for stable scale factor)

Environmental tolerance & agency temperature schedule

• pressure sealing : Viton® O‑ring seals differential pressure between tip and case
• temperature classification (EPL Ga/Gc) : T1 … T5 depending on ambient (T1 up to +232 °C, T5 up to +40 °C)
• for EPL Dc : T280 °C … T90 °C with wide ambient ranges
• chemical resistance : improved over 3300 RAM, suitable for process compressors
• interchangeability : fully backward compatible with previous 3300 RAM probes and extension cables

Frequently asked questions

• can i use this probe with my existing 3300 RAM extension cable? Yes — the 3300 NSv Proximity Probe is mechanically and electrically interchangeable with the 3300 RAM series.
• what is the maximum field wiring distance to the monitor? You can run up to 305 m (1000 ft) of shielded triad cable without significant signal loss.
• does the probe work on small shaft diameters? For shafts below 13 mm, expect some scale factor change. Reducing the initial gap helps maintain accuracy — see Figure 12 in the full manual.
• is the probe pressure tested before shipment? Standard units are not pressure tested. Contact our custom department (Ubest Automation) if you need a validated pressure seal.
• what tools do i need for installation? Only finger‑tight torque for the tip, and a torque wrench for the case if you apply the full 11.3 N·m.
