Overview:

The Bently Nevada 330130-085-10-05 Extension Cable is a robust solution designed to work with 3300 XL proximity probes and is specifically built to withstand industrial environments. Made in the USA, this extension cable comes with optional certifications, including CSA, ATEX, and IECEx approvals. It provides a reliable connection for long-distance measurements in vibration monitoring systems, ensuring high accuracy and performance. The cable features FluidLoc technology to prevent leaks and is available in a length of 8.5 meters (27.9 feet).

Technical Specifications:

• Brand: Bently Nevada
• Model: 330130-085-10-05
• Cable Length Option: 8.5 meters (27.9 feet)
• Connector Protector and Cable Option: 10 FluidLoc cable
• Approvals: CSA, ATEX, IECEx
• Resistance:
  • RCORE (Center Conductor to Center Conductor): 1.87 ± 0.28 Ω (for 8.5m)
  • RJACKET (Outer Conductor to Outer Conductor): 0.56 ± 0.11 Ω (for 8.5m)
• Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft)
• Power Supply: -17.5 Vdc to -26 Vdc (when installed with nonincendive circuit)
• Output Resistance: 50 Ω
• Linear Range: 2 mm (80 mils), starting from approximately 0.25 mm (10 mils) to 2.3 mm (90 mils)
• Field Wiring: 0.2 to 1.5 mm² (16 to 24 AWG)
• Maximum Field Wiring Length: 305 meters (1,000 feet)

Advantages:

• Durability: Designed for long-lasting performance with FluidLoc technology, preventing fluid leaks and protecting the system.
• Approvals: Compliant with international standards (CSA, ATEX, IECEx) for enhanced safety in hazardous areas.
• High Resistance: With low DC resistance, this extension cable ensures minimal signal loss and high fidelity in readings.
• Flexible Installation: Supports various field wiring configurations and can extend up to 305 meters.
