Bently Nevada 3300 XL Sensor 330709-000-060-50-11-00
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Bently Nevada 3300 XL 11mm Proximity Probe: 330709-000-060-50-11-00
The Bently Nevada 330709-000-060-50-11-00 is a high-performance 11 mm proximity probe from the 3300 XL series. This industrial sensor monitors rotating machinery and detects vibration or position changes. It delivers reliable performance in tough industrial environments with its wide operating temperature range.
Detailed Model Number Breakdown
- 330709: 3300 XL 11 mm Probe with M16x1.5 thread, no armor
- 000: Unthreaded length of 0 mm
- 060: Overall case length of 60 mm
- 50: Total cable length of 5.0 meters (for use with 5m Proximitor)
- 11: Miniature coaxial ClickLoc connector with FluidLoc cable
- 00: No agency approvals required
Key Technical Specifications
- Brand: Bently Nevada
- Model: 330709-000-060-50-11-00
- Probe Resistance: 7.2 ± 0.8 ohms
- Minimum Target Size: 30.5 mm diameter flat surface
- Minimum Shaft Diameter: 152 mm recommended
- Probe Tip Material: Polyphenylene sulfide (PPS)
- Case Material: AISI 304 stainless steel
- Cable Type: 75 Ω triaxial with FEP insulation
- Case Torque: 63.3 N•m maximum
- Connector Torque: Finger tight only
- Temperature Range: -52°C to +177°C
- Cable Length: 5.0 meters (16.4 feet)
Installation Guidelines
- Always follow the manufacturer's installation instructions carefully
- Use proper tools to apply the specified case torque during mounting
- Hand-tighten the connector only - do not use tools on the connector
- Maintain minimum cable bend radius of 25.4 mm during installation
- Verify target and shaft meet minimum size requirements for accuracy
- Ensure maximum thread engagement does not exceed 24 mm
Packaging & Shipping
- Each probe ships in secure, protective packaging
- We ship worldwide via FedEx, UPS, and DHL
- Package includes one Bently Nevada 330709-000-060-50-11-00 probe
- All items are carefully inspected before shipment
Frequently Asked Questions (FAQ)
What is the cable length for this probe?
This model has a 5.0 meter cable designed for use with 5-meter Proximitor sensors.
What material is the probe tip made from?
The probe tip uses durable Polyphenylene sulfide (PPS) material.
What is the maximum operating temperature?
The probe operates in temperatures up to 177°C (351°F).
How should I connect the cable?
Hand-tighten the ClickLoc connector only - never use tools.
What is the minimum target size?
Use a flat surface with minimum 30.5 mm diameter for accurate measurements.
Can I use this probe with any Proximitor?
This 5-meter probe requires a matching 5-meter Proximitor sensor.
