Bently Nevada 330103-00-18-10-12-05-3300 XL 8mm Vibration Probe
UBEST – Trusted Global Automation Parts Supplier
We offer a wide range of in-stock industrial automation spare parts. All products come with a 12-month warranty and a 30-day refund for quality issues.
Bently Nevada 3300 XL 8mm Extended Certified Proximity Probe
This professional vibration sensor features extended 180mm length with full safety certifications. Perfect for deep mounting in hazardous areas. Combines maximum reach with explosion-proof protection.
Product Overview
The 330103-00-18-10-12-05 offers extended reach with certified safety. This Bently Nevada probe is ideal for thick-walled machinery. It provides reliable monitoring in explosive atmospheres.
Technical Specifications
- Brand: Bently Nevada
- Model Series: 3300 XL 8mm Proximity Probe
- Complete Part Number: 330103-00-18-10-12-05
- Measurement Range: 2.0 mm (80 mils)
- Voltage Output: -1 Vdc to -17 Vdc
- DC Resistance: 7.59 Ω ± 0.50 Ω
- Operating Temperature: -52°C to +177°C
- Extended Temperature: -52°C to +218°C (tip)
- Case Material: AISI 303/304 Stainless Steel
- Tip Material: PPS (Polyphenylene Sulfide)
- Cable Type: FluidLoc with ClickLoc Connector
- Cable Length: 1.0 meters (3.3 feet)
- Case Length: 180mm
- Thread Size: M10x1
- Weight: 323 g/m (11.4 oz)
- Max Thread Engagement: 15 mm
- Linear Range: 0.25 to 2.3 mm
- Humidity Resistance: Less than 3% ASF change
- Minimum Gap: 0.25 mm from target
- Recommended Gap: 1.27 mm (50 mils)
Part Number Details
- 330103: 3300 XL 8mm Probe, M10x1 thread, no armor
- -00: Unthreaded length = 0mm
- -18: Overall case length = 180mm
- -10: Cable length = 1.0 meters
- -12: ClickLoc connector with FluidLoc cable
- -05: CSA, ATEX, and IECEx certifications
Installation Guide
Set radial vibration gap to -9 Vdc. This equals 1.27 mm target distance. Maximum thread engagement is 15 mm. Viton O-ring ensures reliable environmental sealing.
System Compatibility
This 330103-00-18-10-12-05 works with Bently Nevada 3300 XL systems. Use proper shielded field wiring. Maximum extension length is 305 meters.
Expert Questions
- What applications need 180mm length? Thick-walled machinery and deep housing penetrations.
- Are all three certifications included? Yes, CSA, ATEX, and IECEx for global compliance.
- Can this probe handle chemical exposure? Yes, stainless steel and PPS resist most chemicals.
- What is the installation procedure? Standard mounting with proper gap setting required.
- Is calibration equipment needed? Gap voltage measurement equipment is recommended.
Documentation Download
Download the complete technical datasheet for detailed information. Available here.
