Bently Nevada 330174-00-06-10-12-00: Armored FluidLoc Proximity Probe

Complete Product Configuration Details

Manufacturer: Bently Nevada
Product Line: 3300 Series 5mm Proximity Transducers
Full Model Number: 330174-00-06-10-12-00
330174: 5mm Probe, M8x1 thread, with armor
-00: Unthreaded Length = 0 mm
-06: Overall Case Length = 60 mm
-10: Total Cable Length = 1.0 metre (3.3 feet)
-12: Connector = Miniature coaxial ClickLoc™, FluidLoc cable
-00: Agency Approval = Not required

Technical Performance Specifications

Power Supply Range: Operates on -17.5 Vdc to -26 Vdc, 12 mA max.
System Output Impedance: 50 Ω for standard monitoring system integration.
Probe DC Resistance: 7.59 Ω ± 0.50 at 1.0 meter cable length.
Tip Construction: Polyphenylene sulfide (PPS) material for longevity.
Case Material: Armored AISI 304 stainless steel housing.
Temperature Range: Full operation from -35°C to +177°C.
Magnetic Field Performance: Minimal output variation in 300 Gauss fields.

FAQ – Common Technical Questions

What environments is FluidLoc cable designed for? It is ideal for wet, oily, or humid conditions where standard cables may fail.
What distinguishes this model from others? The Bently Nevada 330174-00-06-10-12-00 offers both armor and FluidLoc sealing.
What material is used for calibration? All specifications assume an AISI 4140 steel target.
What is the default probe gap setting? Performance data is based on a 1.27 mm (50 mil) gap.
Does this model have hazardous area certification? No, the "-00" suffix indicates no special agency approvals.
Where can I view other 5mm probe options? Discover our complete range of 5mm Proximity Probes online.
