Bently Nevada 330707-00-20-50-11-00 Protected Proximity Probe with Armor

This is the heavy-duty Bently Nevada 330707-00-20-50-11-00. It's an 11mm proximity probe with stainless steel armor. It has a 5-meter FluidLoc cable and connector guard. The armor gives extra physical protection. This probe works in tough, oily industrial areas. It pairs with 5-meter Proximitor sensors. Get reliable machine monitoring with this robust sensor.

Complete Product Details

• Brand: Bently Nevada
• Series: 3300 XL with Armor
• Exact Model: 330707-00-20-50-11-00
• Function: 11mm Vibration/Position Probe
• Case Protection: With Stainless Steel Armor
• Mounting Thread: 1/2-20 UNF
• Case Length: 2.0 Inches
• Cable Length: 5.0 Meters (16.4 Feet)
• Cable Type: FluidLoc (Oil/Chemical Resistant)
• Connector: ClickLoc with Protective Cover
• Tip Material: PPS Plastic
• Case/Armor Material: 304 Stainless Steel
• Temp Rating: -51°C to +177°C
• Probe Resistance (5m): 7.2 Ω (± 0.8 Ω)
• Cable Impedance: 75 Ohms Triaxial
• Max Thread Engagement: 0.750 Inches
• Recommended Torque: 15.2 N•m
• Max Torque: 45.2 N•m
• Min Bend Radius: 1.0 Inch

Model Number Decoded Step-by-Step

• BASE 330707 → 3300 XL 11mm Probe, now with armor.
• SUFFIX -00 → Unthreaded shaft length is zero.
• SUFFIX -20 → Overall armored case is 2.0 inches.
• SUFFIX -50 → Total cable is 5.0 meters.
• SUFFIX -11 → FluidLoc cable + Connector Protector.
• SUFFIX -00 → No agency approvals on this model.

Important Installation Guidelines

• This 5-meter probe is for 5-meter Proximitor sensors only.
• The armor protects the cable at the probe exit point.
• Tighten to 15.2 N•m using the 1/2-20 UNF thread.
• Do not engage threads more than 0.75 inches deep.
• The connector protector guards against impact and splash.

Service & Shipping Information

• Compatible with Bently Nevada 3300/3500 systems using 5m sensors.
• The 330707-00-20-50-11-00 is built for harsh conditions.
• Express shipping options: FedEx, UPS, and DHL.
• We provide a strong 12-month product warranty for your confidence.

Technical FAQs Answered

What does "with armor" mean for this probe?

It has a stainless steel sleeve over the cable at the probe body. This armor protects against abrasion, crushing, and physical damage in harsh locations.

Why is this 5-meter probe only for use with 5-meter Proximitors?

The system calibration is matched. Using a 5m probe with a different length sensor will cause incorrect vibration readings.

What is the electrical resistance for this 5-meter version?

The measured resistance from center to outer conductor is 7.2 Ohms, with a tolerance of plus or minus 0.8 Ohms.

Is the thread size different on armored probes?

In this case, yes. Model 330707-00-20-50-11-00 uses a 1/2-20 UNF thread, not the more common 5/8-18. Check your mounting hole.

Can the armored section be bent or adjusted?

No. The stainless steel armor is rigid. Only the flexible cable beyond the armor should be routed, respecting the 1-inch minimum bend radius.
